71247Product Number: 71247-15 Product Number: 71247-70

FALCON 8/50 spot

Dimensions

Dimensions

50 × 5 × 135 mm

50 × 5 × 135 mm
Cut out size

73-83mm
Weight

402 g

402 g

Specification

Material

Aluminium
Color

Black

White
Electrical Safety Class

Class II
IP-Grade

IP20
Electrical Connection

terminal block
IK Rating

IK05
ISOsafe

Yes
EL Number

3246862

3246861
GTIN

7041661276475

7041661276482

Technical

Wattage LED

8W
Total Wattage

8W
Ground Current/Voltage

220-240V
Replaceable LED

No
Supplied Light Sources

Yes
Brightness

605 lm

620 lm
Light Efficiency Luminaire

76 lm/W

77 lm/W
Color Rendering

>90
Color Temperature

2700 K
SDCM

<3
Life Span

80000
Light Angle

24°
Dimmable

Yes
Dimmable Type

Trailing edge / Leading edge
Driver

built-in
UGR Rating

UGR<19
