New
Lynx-27 downlight, black.png
Lynx-27 downlight, black.png
Lynx-27 svart.png
Lynx-27 svart (2).png
Lynx downlight,black (8).png
Lynx downlight, black (5).png
Lynx downlightProduct Number: 71119-15 Product Number: 71119-70 Product Number: 71118-70 Product Number: 71118-15

Lynx downlight

Dimensions

Dimensions

90 × 9 × 35 mm

90 × 9 × 35 mm

90 × 9 × 35 mm

90 × 9 × 35 mm
Cut out size

73-83mm
Recess Depth

33mm
Weight

195 g

195 g

195 g

195 g

Specification

Material

Aluminium
Color

Black

White

White

Black
Electrical Safety Class

Class II
IP-Grade

IP44
Electrical Connection

terminal block
IK Rating

IK07
ISOsafe

Yes
GTIN

7041661285422

7041661285439

7041661285415

7041661285408

Technical

Wattage LED

7W
Total Wattage

8W
Ground Current/Voltage

220-240V
Replaceable LED

No
Supplied Light Sources

Yes
Brightness

650 lm

660 lm

640 lm

630 lm
Light Efficiency Luminaire

81 lm/W

83lm/W

80 lm/W

79 lm/W
Color Rendering

>97
Color Temperature

3000K

3000K

2700K

2700K
SDCM

<3
Life Span

137000
Light Angle

36°
Dimmable

Yes
Dimmable Type

Trailing edge / Leading edge
Driver

external included
UGR Rating

UGR<18

UGR<19

UGR<19

UGR<18
