Lynx downlightProduct Number: 71119-15 Product Number: 71119-70 Product Number: 71118-70 Product Number: 71118-15

Lynx downlight

Dimensions

Dimensions

90 × 9 × 35 mm

90 × 9 × 35 mm

90 × 9 × 35 mm

90 × 9 × 35 mm
Cut out size

73-83mm
Recess Depth

33mm
Weight

195 g

195 g

195 g

195 g

Specification

Material

Aluminium
Color

Black

White

White

Black
Electrical Safety Class

Class II
IP-Grade

IP44
Electrical Connection

terminal block
IK Rating

IK07
ISOsafe

Yes
EL Number

3204948

3204949

3204947

3204946
GTIN

7041661285422

7041661285439

7041661285415

7041661285408

Technical

Wattage LED

7W
Total Wattage

8W
Ground Current/Voltage

220-240V
Replaceable LED

No
Supplied Light Sources

Yes
Brightness

650 lm

660 lm

640 lm

630 lm
Light Efficiency Luminaire

81 lm/W

83lm/W

80 lm/W

79 lm/W
Color Rendering

>97
Color Temperature

3000K

3000K

2700K

2700K
SDCM

<3
Life Span

137000
Light Angle

36°
Dimmable

Yes
Dimmable Type

Trailing edge / Leading edge
Driver

external included
UGR Rating

UGR<18

UGR<19

UGR<19

UGR<18
