69415f725eff564697f5b684Product Number: 71229-15 Product Number: 71230-15 Product Number: 71231-15

Scanled Pro-27 svart

Net Length

249

548

848

Clear

Dimensions

Dimensions

249 × 2,54 × 14 mm

548 × 2,54 × 14 mm

848 × 2,54 × 14 mm

Weight

85 g

175 g

263 g

Specification

Material	Aluminum/plastic
Color	Black
Electrical Safety Class	Class II
IP-Grade	IP20
Electrical Connection	Adapter för skena
EL Number	3204981 3204982 3204983
GTIN	7041661283336 7041661283343 7041661283350

Technical

Total Wattage	4W 9W 12W
Ground Current/Voltage	220-240V 220-240 220-240V
Replaceable LED	No
Supplied Light Sources	Yes
Brightness	210lm 550lm 730lm
Light Efficiency Luminaire	52lm/W 62lm/W 61lm/W
Color Rendering	>90
Color Temperature	svart 2700 2700
SDCM	<4
Life Span	50000
Light Angle	113°
Dimmable	Yes Yes No
Dimmable Type	Trailing edge / Leading edge
Driver	built-in
UGR Rating	UGR<29
