71110Product Number: 71110-70-70 Product Number: 71111-70-15 Product Number: 71112-70-29 Product Number: 71113-15-15 Product Number: 71114-15-29

STYX downlight

Dimensions

Dimensions

90 × 9 × 49 mm

90 × 9 × 49 mm

90 × 9 × 49 mm

90 × 9 × 49 mm

90 × 9 × 49 mm

Cut out size

80-83mm

Recess Depth

48mm

Weight

234 g

234 g

234 g

234 g

234 g

Specification

Material

Aluminum/plastic

Color

White

White / Black

White / Copper

Black / Black

Black / Copper

Electrical Safety Class

Class II

IP-Grade

IP44

EL Number

3210637

3210638

3210639

3210640

3210641

GTIN

7041661272927

7041661272934

7041661272958

7041661273511

7041661272941

Technical

Wattage LED

7,5W

Ground Current/Voltage

200mA Actec DC20-40V AC220-240V

Replaceable LED

No

Max Wattage

7,5W

7,5W

Max 60W

7,5W

7,5W

Supplied Light Sources

Yes

Brightness

595 lm

595 lm

595 lm

545 lm

545 lm

Color Rendering

>95

Color Temperature

2700K

SDCM

<3

Life Span

100000

Light Angle

35°

Dimmable

Yes

Dimmable Type

Trailing edge / Leading edge

Driver

external included
