TRACKLINE FALCON 8/50

Dimensions

Dimensions	50 × 5 × 135 mm 50 × 5 × 135 mm
Weight	330 g 330 g

Specification

Material	Aluminium
Color	Black White
Electrical Safety Class	Class I
IP-Grade	IP20
Electrical Connection	Adapter för skena
IK Rating	IK05
Mounting Principle	fully assembled
GTIN	7041661276277 7041661276284

Technical

Wattage LED	8W
Total Wattage	8W
Ground Current/Voltage	220-240V
Replaceable LED	No
Supplied Light Sources	Yes
Brightness	605 lm 620 lm
Light Efficiency Luminaire	76 lm/W 77 lm/W
Color Rendering	>90
Color Temperature	2700 K
SDCM	<3
Life Span	80000
Light Angle	24°
Dimmable	Yes
Dimmable Type	Trailing edge / Leading edge
Driver	built-in
UGR Rating	UGR<19

Downloads

Images

Product picture 1Product picture 2Detail picture 1Detail picture 2Detail picture 3Detail picture 4

Images

Product pictureDetail picture 1Detail picture 2

Images

Product pictureDetail picture 1Detail picture 2

Accessories

• TRACKLINE track 1m

  Product Number: 71703-15

• TRACKLINE track 1m

  Product Number: 71741-15

• TRACKLINE track 1m

  Product Number: 71741-70
