RING 20/400 evo

Product Number: 71044-15
Main Color

The upgraded RING evo luminaire is smarter, stronger, and more flexible than ever before! With its sleek, slim design and high light output, it fits perfectly in both private and professional environments. Regardless of the room, RING ensures optimal lighting thanks to flexible mounting options, high color rendering (CRI>90), and a long lifespan (165,000 hours).

Installation is quick and easy! RING comes with a bracket for ceiling or wall mounting, as well as a spacer bracket for installation with open wiring. Specially developed with electricians in mind, it ensures a smooth and hassle-free installation.

On the back, you’ll find a convenient switch where you can easily choose the color temperature (2700K, 3000K, or 4000K), allowing you to tailor the light to the application. If you choose the DALI version, you get even greater flexibility with adjustable color temperature from 2700K to 6500K (Tunable White).

RING is available in several variants with different sizes and light outputs. If you want extra functionality, you can choose a model with a motion sensor, DALI control, or a wire kit for suspended installation.

Upgrade to RING evo – the perfect combination of style, brightness, and user-friendliness!

Dimensions
Dimensions

397 × 39,7 × 24 mm

397 × 39,7 × 24 mm

Weight

1255 g

1255 g

Specification
Material

Plastic

Color

Black

White

Electrical Safety Class

Class II

IP-Grade

IP20

Electrical Connection

cable

IK Rating

IK05

GTIN

7041661283213

7041661283220

Technical
Wattage LED

17W

Total Wattage

19W

Ground Current/Voltage

220-240V

Replaceable LED

No

Supplied Light Sources

Yes

Brightness

1900lm

2040lm

Light Efficiency Luminaire

100lm/W

110lm/W

Color Rendering

<90

Color Temperature

2700/3000/4000K

SDCM

4

Life Span

165000

Light Angle

110°

Dimmable

Yes

Dimmable Type

Trailing edge / Leading edge

Driver

built-in

UGR Rating

UGR<22
